Orifice Flange Assembly

High Accuracy and Reliability

Designed for precise measurement of flow rates, offering a high degree of accuracy and repeatability.Conforms to industry standards such as ASME, ISO, and AGA for consistent and reliable performance.

Robust Construction

Manufactured from high-quality materials such as stainless steel, carbon steel, and other corrosion- resistant alloys to withstand harsh industrial conditions.Suitable for high-pressure and high-temperature applications, providing long-term durability and reliability.

Versatile Design

Available in various configurations, including concentric, eccentric, and segmental orifice plates, to meet specific application requirements.Can be used with a wide range of fluids, including liquids, gases, and steam, making it suitable for diverse industrial applications.

Easy Installation and Maintenance

Designed for straightforward installation between pipeline flanges, with standard flange connections for easy integration into existing systems.The orifice plate can be easily removed for inspection, cleaning, or replacement without dismantling the entire assembly.

Customizable Options

Available in different sizes, materials, and pressure ratings to suit specific application needs.Custom-designed orifice plates and flange assemblies can be provided to meet unique process requirements.

Technical Specifications

Measuring Range

Material Options: Stainless steel, carbon steel, Hastelloy, Inconel, and other corrosion-resistant alloys.

Operating Temperature

Operating Temperature: Suitable for temperatures up to 600°C (1112°F) or higher with special designs.

Operating Pressure

Operating Pressure: Can withstand pressures up to 250 bar (3625 psi) or higher with reinforced construction.

Material Options

Orifice Plate Types: Concentric, eccentric, segmental, and quarter-circle plates to suit various flow measurement applications.

Float Size and Material

Connection Types: Flanged connections (ANSI, DIN, JIS) for easy integration into pipeline systems.

Indicator Board

Sizes: Available in sizes ranging from 1/2 inch to 24 inches or larger, customizable to meet specific application requirements.

Applications

Oil and Gas

Oil and Gas Flow measurement of crude oil, natural gas, and other process fluids in pipelines, refineries, and offshore platforms.

Chemical Processing

Water Treatment Measurement of water and wastewater flow rates in treatment plants, ensuring accurate monitoring and control.

Water Treatment

Power Generation Flow measurement of boiler feed water, steam, and cooling water in power plants, ensuring efficient operation.

Food and Beverage

Food and Beverage Flow measurement of ingredients, process fluids, and cleaning agents in food and beverage production processes.

Benefits

Orifice Flange Assemblies are essential for industries requiring precise and reliable flow measurement solutions. With their robust construction, versatile design, and high-performance capabilities, our orifice flange assemblies ensure optimal flow measurement and process control. By choosing our orifice flange assemblies, you benefit from superior accuracy, enhanced safety, and long-term operational efficiency.For more information or to request a quote, please contact us at sales@globeunitedae.com.

Enhanced Process Control:

Provides accurate and reliable flow measurement, ensuring optimal process control and efficiency.

Improved Safety:

Accurate flow measurement helps prevent overflows, leaks, and other hazardous situations.

Cost-Effective:

Durable construction and low maintenance requirements contribute to reduced long- term operational costs.

Flexible Integration:

Wide range of sizes, materials, and customization options make it easy to integrate the assembly into various systems and applications.

Compliance with Standards:

Conformance to industry standards ensures reliable and consistent performance across diverse applications.
