Selecting the right Differential Pressure Transmitters is critical for achieving accurate process control and reliable plant performance. Choosing the wrong mounting configuration can lead to measurement inaccuracies, frequent maintenance, premature instrument failure, and costly production downtime. Whether you’re monitoring flow, tank levels, or filter conditions, the mounting style plays a significant role in overall system reliability.
The two most common options are Direct Mount Differential Pressure Transmitters and Capillary Differential Pressure Transmitters. While both perform the same fundamental function, they are designed for different process conditions. This guide explains how each type works, compares their advantages and limitations, and helps engineers select the best solution for their application.
What Are Differential Pressure Transmitters?
Differential Pressure Transmitters measure the pressure difference between two process points using High Pressure (HP) and Low Pressure (LP) ports. The measured differential pressure is converted into an electrical signal that can be monitored by PLCs, DCS systems, or SCADA platforms.
They are widely used across Process Instrumentation and Industrial Automation applications, including:
- Flow measurement using orifice plates, venturi tubes, and flow nozzles
- Tank level measurement in closed vessels
- Filter and strainer monitoring
- Density and interface measurement
- Pump and compressor performance monitoring
Accurate Differential Pressure Measurement helps improve process efficiency, equipment protection, and product quality.
What Is a Direct Mount Differential Pressure Transmitter?
A Direct Mount Differential Pressure Transmitter is installed directly onto the process connection without using remote seals or capillary tubing. The sensing element remains in close contact with the process pressure, providing fast and highly responsive measurements.
Advantages
- Compact and simple installation
- Faster response time
- High measurement accuracy under stable conditions
- Lower installation cost
- Easier calibration and maintenance
Disadvantages
- Limited suitability for high-temperature processes
- Not ideal for corrosive or highly viscous media
- Process fluids may damage sensing components over time
Ideal Applications
Direct mount transmitters are commonly used in:
- Water treatment plants
- HVAC systems
- Utility services
- General manufacturing
- Clean process fluids with moderate temperatures
What Is a Capillary Differential Pressure Transmitter?
A Capillary Differential Pressure Transmitter, also known as a Remote Seal Pressure Transmitter, uses diaphragm seals connected by fluid-filled capillary tubes. Instead of exposing the sensing element directly to the process, pressure is transmitted through the fill fluid inside the capillary.
This Remote Seal System isolates the transmitter from harsh process conditions while maintaining reliable pressure measurement.
How the Remote Seal System Works
Isolation for Better Protection
The isolation diaphragm contacts the process fluid, while the internal fill fluid transfers pressure through the capillary tubing to the transmitter sensor. This design protects the sensing element from:
- High temperatures
- Corrosive chemicals
- Sticky or viscous fluids
- Crystallizing products
- Hygienic or sanitary process media
Advantages
- Excellent for High Temperature Pressure Measurement
- Protects sensitive sensing elements
- Suitable for corrosive and abrasive fluids
- Supports remote installation where access is difficult
- Improves long-term reliability
Disadvantages
- Higher initial investment
- Slower response compared to direct mount systems
- More complex installation
- Requires proper capillary routing to maintain accuracy
Typical Industries
Capillary systems are widely used in:
- Oil & Gas
- Chemical processing
- Pharmaceutical manufacturing
- Food & Beverage
- Power plants
- Pulp & Paper industries
Capillary vs Direct Mount Differential Pressure Transmitters
| Feature | Direct Mount | Capillary |
| Accuracy | Excellent under normal conditions | Excellent for harsh processes |
| Response Time | Very fast | Slightly slower |
| Installation | Simple | More complex |
| Initial Cost | Lower | Higher |
| Maintenance | Easy | Moderate |
| High Temperature | Limited | Excellent |
| Corrosive Fluids | Not recommended | Highly suitable |
| Long Distance Installation | Limited | Excellent |
| Process Safety | Moderate | High |
| Best Applications | Clean utilities, water, HVAC | Chemical, oil & gas, sanitary, high-temperature processes |
When Should You Choose Direct Mount?
A Direct Mount Differential Pressure Transmitter is the preferred choice when process conditions are relatively clean and stable.
It works best for:
- Water treatment facilities
- HVAC applications
- Utility systems
- General manufacturing plants
- Standard liquid and gas pressure measurement
- Short installation distances
When the process fluid is non-corrosive and temperatures remain within transmitter limits, direct mounting provides excellent performance with lower installation costs.
When Should You Choose Capillary Type?
A Capillary Differential Pressure Transmitter becomes the better option when harsh process conditions could damage the sensing element.
Typical situations include:
- High-temperature process lines
- Corrosive chemicals
- Highly viscous liquids
- Crystallizing media
- Sanitary pharmaceutical and food processes
- Hazardous or inaccessible installations
Remote seals isolate the transmitter from aggressive process media, significantly improving instrument reliability while reducing maintenance frequency.
Key Factors to Consider Before Selecting Differential Pressure Transmitters
Choosing the right Industrial Pressure Transmitter involves evaluating more than pressure range alone.
Consider the following:
- Process Temperature – High temperatures often require capillary systems.
- Pressure Range – Match transmitter specifications with operating conditions.
- Chemical Compatibility – Verify diaphragm and wetted material compatibility.
- Installation Distance – Long distances may require a Remote Seal System.
- Maintenance Accessibility – Select configurations that simplify servicing.
- Accuracy Requirements – Critical applications demand higher measurement stability.
- Response Time – Fast-changing processes benefit from direct mount installations.
- Total Lifecycle Cost – Consider maintenance, downtime, and replacement costs—not just purchase price.
Proper Pressure Transmitter Selection ensures improved safety, longer equipment life, and reduced operational costs.
